Common Welding Positioner Types

The basic forms of the commonly used manual welding positioner such as Rotating Type Welding Positioner are the outrigger type, the tilting type and the double column single rotation type.

(1) Double-column single-rotation The main feature of this type of welding positioner is that the motor-driven working device at one end of the column runs in one direction of rotation and the other end is driven with the active end.

(2) Two-seat head-to-tail double-rotating two-seat head-to-tail double-slewing welding positioner is the movable space of the welded structural part, and adds a rotation degree of freedom on the basis of the double-column single-rotation welding positioner. .

(3) L-shaped double-rotation type The working position of this type of welding positioner is L-shaped, with two degrees of freedom of rotation, and both directions can be arbitrarily rotated by ±360°.

(4) C-shaped double-rotation C-shaped double-slewing welding positioner is the same as the L-shaped double-slewing welding positioner, except that the fixture of the welding positioner is slightly changed according to the shape of the structural member.
